◆Highly transparent quartz condenser lens, small light spot, high energy
◆High-power air-cooled heat dissipation, can be used continuously
◆Light intensity up to 5300mW/cm² at 20mm working distance
◆ Bonding of digital cameras, mobile phones, camera lenses, and small optical lenses
◆ Semiconductor chip packaging, sensor production, hard disk head bonding
◆ Medical device injection head bonding
◆ Ink, varnish, paint curing
◆ Touch screen glue edge sealing, LCD panel potting port packaging
◆ PCB board chip UV adhesive bonding
Model | Color | Wavelength | Emitting Size | Voltage | Power |
---|---|---|---|---|---|
HS-PB-100-30-UV365 | UV | 365nm | 100mm*30mm | 24V | 36W |
HS-PB-120-30-UV365 | UV | 365nm | 120mm*30mm | 24V | 42W |
HS-PB-150-30-UV365 | UV | 365nm | 150mm*30mm | 24V | 48W |
HS-PB-180-30-UV365 | UV | 365nm | 180mm*30mm | 24V | 64W |
HS-PB-100-30-UV385 | UV | 385nm | 100mm*30mm | 24V | 36W |
HS-PB-120-30-UV385 | UV | 385nm | 120mm*30mm | 24V | 42W |
HS-PB-150-30-UV385 | UV | 385nm | 150mm*30mm | 24V | 48W |
HS-PB-180-30-UV385 | UV | 385nm | 180mm*30mm | 24V | 64W |
HS-PB-100-30-UV395 | UV | 395nm | 100mm*30mm | 24V | 36W |
HS-PB-120-30-UV395 | UV | 395nm | 120mm*30mm | 24V | 42W |
HS-PB-150-30-UV395 | UV | 395nm | 150mm*30mm | 24V | 48W |
HS-PB-180-30-UV395 | UV | 395nm | 180mm*30mm | 24V | 64W |
HS-PB-100-30-UV405 | UV | 405nm | 100mm*30mm | 24V | 36W |
HS-PB-120-30-UV405 | UV | 405nm | 120mm*30mm | 24V | 42W |
HS-PB-150-30-UV405 | UV | 405nm | 150mm*30mm | 24V | 48W |
HS-PB-180-30-UV405 | UV | 405nm | 180mm*30mm | 24V | 64W |
