◆High-density LED array, high brightness
◆Compact design saves installation space
◆Optional diffuser plate to diffuse light evenly
◆Efficient heat dissipation structure improves light source stability
◆ Defect detection of glass end face
◆ Appearance and character detection
◆ O-ring appearance inspection
◆ Damage, defect, edge detection
◆ QR code, 1D code barcode reading
◆ Foreign object detection on wafer
◆ Color recognition detection
◆ Detection of foreign matter contamination in pharmaceuticals
Model | Color | Angle | Outside Diameter | Inside Diameter | Power |
---|---|---|---|---|---|
HS-RI0-100-40-R | Red | 0° | 100mm | 40mm | 5W/24V |
HS-RI0-100-40-G | Green | 0° | 100mm | 40mm | 5W/24V |
HS-RI0-100-40-B | Blue | 0° | 100mm | 40mm | 5W/24V |
HS-RI0-100-40-W | White | 0° | 100mm | 40mm | 5W/24V |
HS-RI30-120-50-R | Red | 30° | 120mm | 50mm | 10W/24V |
HS-RI30-120-50-G | Green | 30° | 120mm | 50mm | 10W/24V |
HS-RI30-120-50-B | Blue | 30° | 120mm | 50mm | 10W/24V |
HS-RI30-120-50-W | White | 30° | 120mm | 50mm | 10W/24V |
HS-RI45-180-110-R | Red | 45° | 180mm | 110mm | 15W/24V |
HS-RI45-180-110-G | Green | 45° | 180mm | 110mm | 15W/24V |
HS-RI45-180-110-B | Blue | 45° | 180mm | 110mm | 15W/24V |
HS-RI45-180-110-W | White | 45° | 180mm | 110mm | 15W/24V |
HS-RI60-200-160-R | Red | 60° | 200mm | 160mm | 13W/24V |
HS-RI60-200-160-G | Green | 60° | 200mm | 160mm | 13W/24V |
HS-RI60-200-160-B | Blue | 60° | 200mm | 160mm | 13W/24V |
HS-RI60-200-160-W | White | 60° | 200mm | 160mm | 13W/24V |
