◆Color can be customized, R/G/B/W/IR/UV
◆IR wavelength customization range : 800-1700nm
◆UV wavelength customization range : 200-400nm
◆Highly bright, small, compact, efficient heat dissipation
◆Replacement for fiber optic halogen lamps, especially suitable as coaxial illumination of lenses
◆ Wafer positioning and defect detection
◆ Filter surface defect detection
◆ Mark point positioning
◆ Edge positioning detection of products with height differences
◆ Special light source for coaxial lens
◆ Flat object positioning detection
◆ Differentiation and positioning detection of different materials
Model | Color | Outlet Diameter | Outside Diameter | Length | Current | Power |
---|---|---|---|---|---|---|
HS-PO-08-03-R | Red | Φ8mm | 24mm | 60mm | 1A | 3W |
HS-PO-08-03-G | Green | Φ8mm | 24mm | 60mm | 1A | 3W |
HS-PO-08-03-B | Blue | Φ8mm | 24mm | 60mm | 1A | 3W |
HS-PO-08-03-W | White | Φ8mm | 24mm | 60mm | 1A | 3W |
HS-PO-08-03-IR | IR | Φ8mm | 24mm | 60mm | 1A | 2W |
HS-PO-08-03-UV | UV | Φ8mm | 24mm | 60mm | 1.5A | 5W |
HS-PO-35-05-R | Red | Φ11mm | 35mm | 60mm | 2A | 5W |
HS-PO-35-05-G | Green | Φ11mm | 35mm | 60mm | 2A | 5W |
HS-PO-35-05-B | Blue | Φ11mm | 35mm | 60mm | 2A | 5W |
HS-PO-35-05-W | White | Φ11mm | 35mm | 60mm | 2A | 5W |
HS-PO-35-05-IR | IR | Φ11mm | 35mm | 60mm | 2A | 5W |
HS-PO-35-05-UV | UV | Φ11mm | 35mm | 60mm | 2A | 6W |
