◆Global Shutter CMOS Image Sensor
◆Maximum resolution: 65 million pixels
◆Full resolution maximum frame rate:335fps
◆Multiple wide dynamic range (HDR) mode support
◆ SMT automatic optical inspection
◆ Wafer surface inspection
◆ Semiconductor packaging inspection
◆ Bioimaging, medical imaging
◆ High-end surveillance
| Resolution | Mono/Color | Pixel Size | Maximum framerate | Data Interface |
|---|---|---|---|---|
| 2048 * 1088 | M / C | 5.5μm * 5.5μm | 335fps@10Tap；280fps@8Tap；140fps@4Tap；71fps@2Tap | Camera Link |
| 1936 * 1472 | M | 4.5μm * 4.5μm | 409 fps | 10GigE Vision |
| 2048 * 2048 | M / C | 5.5μm * 5.5μm | 180fps@10Tap；150fps@8Tap；75fps@4Tap；38fps@2Tap | Camera Link |
| 2560 * 2048 | M | 5μm * 5μm | 156 fps | Camera Link |
| 2592 * 2048 | M / C | 4.8μm * 4.8μm | 105fps@8bit，87fps@10bit | CoaXPress |
| 3216 * 2208 | M | 4.5μm * 4.5μm | 171 fps | 10GigE Vision |
| 4096 * 3072 | M / C | 5.5μm * 5.5μm | 181 fps | CoaXPress |
| 4096 * 3072 | M / C | 5.5μm * 5.5μm | 190.9fps@8bit，154.3fps@10bit | CoaXPress |
| 5120 * 4096 | M / C | 4.5μm * 4.5μm | 231.05fps@8bit，179.60fps@10bit，152.44fps@12bit | CoaXPress12 |
| 5120 * 5120 | M | 2.5μm * 2.5μm | 41.79fps@8bit，35.98fps@10bit，30.48fps@12bit | CoaXPress |
| 5120 * 5120 | M | 4.5μm * 4.5μm | 85.099fps@8bit，70.225fps@10bit | CoaXPress |
| 5120 * 5120 | M / C | 2.5μm * 2.5μm | 2 channels：91.2fps@8bit，73.8fps@10bit ；4 channels：150.1fps@8bit，141.0fps@10bit | CoaXPress12 |
| 9344 * 7000 | M / C | 3.2μm * 3.2μm | 2 channels：18.58fps@8bit，14.21fps@10bit，12.36fps@12bit ；4 channels：31.59fps@8bit， | CoaXPress |
| 6464 * 4852 | M / C | 3.45μm * 3.45μm | 35.85fps@8bit，30.57fps@10bit，25.52fps@12bit | CoaXPress BNCx2 |
| 9344 * 7000 | M / C | 3.2μm * 3.2μm | 71.04fps@8bit；58.13fps@10bit | CoaXPress12 |
| 4096 * 3072 | M / C | 5.5μm * 5.5μm | 65.28fps@8bit，52.53fps@10bit | Camera Link |
| 4192 * 2160 | M / C | 2.5μm * 2.5μm | 261.56fps@8bit，211.28fps@10bit | CoaXPress12 |
