◆ Global shutter CMOS sensor
◆ Maximum line frequency 80Khz
◆ Minimum exposure time 2μs, exposure time step 0.01μs
◆ Analog Gain/Digital Gain/Offset Control
Resolution | Mono/Color | Pixel Size | Maximum Line Frequency | Data Interface |
---|---|---|---|---|
4096 * 1(4K) | M | 3.5μm * 3.5μm | 30kHz(80kHz with SAccel™) | GigE Vision |
7500 * 4(7K) | C | 9.325μm * 9.325μm | 8.6 kHz | Camera Link |
8192 * 1(8K) | M | 7μm * 7μm | 15kHz(45kHz with SAccel™) | GigE Vision |
8192 * 1(8K) | M | 7μm * 7μm | 80.5kHz@8bit,74.5kHz@10bit | 10GigE Vision(SFP+) |
8192 * 1(8K) | M | 7μm * 7μm | 80.0kHz@8Tap,40.2kHz@4Tap,20.1kHz@2Tap | Camera Link |
1/2Tap:15424 * 3 ;3Tap:15420 * 3(15K) | M | 5.6μm * 5.6μm | 45kHz@10tap,42kHz@8tap,21kHz@4tap,11kHz@2tap | Camera Link |
16384 * 1(16K) | M | 3.5μm * 3.5μm | 51Khz | Camera Link |
16384 * 1(16K) | M | 3.5μm * 3.5μm | 80Khz | CoaXPress |
16384 * 1(16K) | M | 3.5μm * 3.5μm | 74.8kHz@8bit,35.4kHz@10bit | 10GigE Vision(SFP+) |
