Small and medium format scanning cameras

Product Features

◆Global shutter CMOS sensor

◆Maximum resolution 12 million pixels

◆Maximum frame rate in compressed mode 107fps

◆Gigabit Ethernet interface, suitable for long-distance transmission

Application scope

◆ Industrial vision positioning

◆ Quick size measurement

◆ Surface inspection of various industrial scenes

Resolution	Mono/Color	Pixel Size	Maximum framerate	Data Interface
1440 * 1080	M / C	3.45μm * 3.45μm	79fps（107fps with SAccel™）	GigE Vision
1920 * 1200	M / C	5.86μm * 5.86μm	42 fps	GigE Vision
2048 * 1536	M / C	3.45μm * 3.45μm	39fps（56fps with SAccel™）	GigE Vision
2448 * 2048	M / C	3.45μm * 3.45μm	25fps（36fps with SAccel™）	GigE Vision
4096 * 2168	M / C	3.45μm * 3.45μm	14fps（21fps with SAccel™）	GigE Vision
4096 * 3000	M / C	3.45μm * 3.45μm	10fps（15fps with SAccel™）	GigE Vision
4096 * 3000	M / C	3.45μm * 3.45μm	11.84fps@8/12bit	USB3.0
5544 * 3688	M / C	2.4μm * 2.4μm	6fps（9fps with SAccel™）	GigE Vision
4024 * 3036	M / C	1.85μm * 1.85μm	10fps（15fps with SAccel™）	GigE Vision
