| Model | Focus | Aperture | Min distance | Max image surface size |
TV | Filter Size | Lenses Size | Visual Field Horizontal * Vertical * Diagonal |
Weight |
|---|---|---|---|---|---|---|---|---|---|
| HS-LEN-1220-10MP | 12mm | F2.0-F22 | 0.1m | 1" | -0.80% | M37.5*P0.5 | φ42.6*62.4mm |
1" 67.60°*56.70°*43.50° 1/2" 36.17°*30.10°*23.13° 1/3" 27.78°*23.14°*16.97° |
202g |
| HS-LEN-1620-10MP | 16mm | F2.0-F22 | 0.1m | 1" | -0.70% | M34*P0.5 | φ37.4*50.7mm |
1" 53.94°*43.92°*33.45° 1/2" 28.23°*22.62°*16.97° 1/3" 21.24°*16.98°*12.94° |
101g |
| HS-LEN-2518-10MP | 25mm | F1.8-F16 | 0.15m | 1" | -0.49% | M30.5*P0.5 | φ33*35.7mm |
1" 36.21°*29.08°*21.86° 1/2" 18.45°*14.72°*11.08° 1/3" 13.81°*11.08°*8.340° |
74g |
| HS-LEN-3520-10MP | 35mm | F2.0-F16 | 0.2m | 1" | 0.28% | M30.5*P0.5 | φ35.7*40.4mm |
1" 26.10°*20.83°*15.72° 1/2" 13.28°*10.65°*7.94° 1/3" 9.920°*7.920°*6.00° |
70g |
| HS-LEN-5020-10MP | 50mm | F2.0-F22 | 0.25m | 1" | -0.01% | M37.5*P0.5 | φ42.4*52.3mm |
1" 18.38°*14.70°*10.98° 1/2" 9.340°*7.420°*5.500° 1/3" 6.960°*5.520°*3.800° |
105g |
| HS-LEN-7528-10MP | 75mm | F2.8-F22 | 0.5m | 1" | -0.011% | M39*P0.5 | φ43*64.4mm |
1" 12.3°*4.80°*7.40° 1/2" 6.20°*7.42°*5.50° 1/3" 4.70°*3.60°*2.70° |
178g |
