| Model | Focus | Aperture | Min distance | Max image surface size |
TV | Filter Size | Lenses Size | Visual Field Horizontal * Vertical * Diagonal |
Weight |
|---|---|---|---|---|---|---|---|---|---|
| HS-LEN-1228-20MP | 12mm | F2.8-F22 | 0.1m | 1.1" | -0.85% | M37.5*P0.5 | φ42.4*62.4mm |
1.1" 70.6°*59.20°*45.40° 1" 67.60°*56.70°*43.50° 1/2" 37.00°*49.40°*22.00° 1/3" 27.60°*2.100°*16.80° |
202g |
| HS-LEN-1628-20MP | 16mm | F2.8-F22 | 0.1m | 1.1" | -0.73% | M34*P0.5 | φ37.4*45.9mm |
1.1" 58.6°*46.88°*35.16° 1" 53.94°*43.92°*33.45° 1/2" 28.23°*22.62°*16.94° 1/3" 21.24°*16.98°*12.94° |
101.25g |
| HS-LEN-2528-20MP | 25mm | F2.8-F22 | 0.15m | 1.1" | -0.59% | M30.5*P0.5 | φ33.5*36.5mm |
1.1" 49.46°*31.56°23.60° 1" 36.21°*29.08°*21.86° 1/2" 18.45°*14.72°*11.08° 1/3" 13.81°*11.08°*8.340° |
72.2g |
| HS-LEN-3528-20MP | 35mm | F2.8-F22 | 0.2m | 1.1" | 0.37% | M30.5*P0.5 | φ35.7*35.2mm |
1.1" 28.18°*22.54°*16.90° 1" 26.10°*20.83°*15.72° 1/2" 13.28°*10.65°*7.940° 1/3" 9.920°*7.920°*6.000° |
68.35g |
| HS-LEN-5028-20MP | 50mm | F2.8-F22 | 0.25m | 1.1" | -0.06% | M37.5*P0.5 | φ42.4*48.3mm |
1.1" 19.96°*15.96°*11.96° 1" 18.38°*14.70°*10.98° 1/2" 9.340°*7.420°*5.500° 1/3" 6.960°*5.350°*4.160° |
103.1g |
