8 megapixel fixed focus lens

Product Description

High resolution, 8 million 2.74um chip, ultra-low distortion, zero distortion @ 290-350mm working distance, no heating, -20 °~+60 ° image without virtual focus, compatible with up to 2/3 '8 million pixel cameras, focusing range from 200mm to infinity without the need for an extension circle, anti shake design, optional manual locking nail style and clamping method

Product Features

Model	Focus	Aperture	Min distance	Max image surface size	TV	Filter Size	Lenses Size	Visual Field Horizontal * Vertical * Diagonal	Weight
HS-LEN-1624-20MP	16mm	F2.4-F11	0.1m	2/3"	0.51%@330mm	M27*P0.5	φ31*29mm	1/2.5" 20.001°14.934°24.879° 1/1.8" 23.454°19.633°30.867° 2/3" 6.961°26.887°37.339°	40g
HS-LEN-1628-20MP	16mm	F2.8-F16	0.2m	2/3"	0%@330mm	M27*P0.5	φ31*25mm	1/2.5" 08.945°11.981°14.525° 1/1.8" 11.757°14.052°18.603° 2/3" 16.160°16.210°22.650°	36g
HS-LEN-3524-20MP	35mm	F2.4-F16	0.2m	2/3"	0%@350mm	M27*P0.5	φ31*26mm	1/2.5"08.240°06.115°10.305° 1/1.8" 09.696°08.085°12.886° 2/3" 11.200°11.169°15.738°	45g
HS-LEN-5024-20MP	50mm	F2.4-F16	0.2m	2/3"	0%@290mm	M27*P0.5	φ31*40mm	1/2.5" 05.389°04.015°06.738° 1/1.8"06.327°05.288°08.419° 2/3" 7.307°07.286°10.257°	58g
