| Model | Focus | Aperture | Min distance | Max image surface size |
TV | Filter Size | Lenses Size | Visual Field Horizontal * Vertical * Diagonal |
Weight |
|---|---|---|---|---|---|---|---|---|---|
| HS-LEN-2035-25MP | 20mm | F3.5-F11 | 0.15m | 1.2" | 0%@490mm | M30.5*0.5 | φ34.0*24mm |
1" 34.831°*23.642°*41.861° 1.1" 34.019°*34.019°*45.631° 1/2" 38.426°*33.537°*49.524° |
42g |
| HS-LEN-2528-25MP | 25mm | F2.8-F16 | 0.15m | 1.2" | 0%@420mm | M30.5*0.5 | φ34.0*29mm |
1" 28.040°*18.891°*33.861° 1.1" 27.340°*27.340°*36.984° 1/2" 30.962°*26.945°*40.269° |
51g |
| HS-LEN-3528-25MP | 35mm | F2.8-F16 | 0.2m | 1.2" | 0%@215mm | M30.5*0.5 | φ34.0*33mm |
1" 19.271°*12.935°23.38° 1.1" 18.804°*18.804°*25.636° 1/2" 21.350°*18.527°*28.010° |
59g |
| HS-LEN-5028-25MP | 50mm | F2.8-F16 | 0.2m | 1.2" | 0%@330mm | M30.5*0.5 | φ34.0*42mm |
1" 12.907°*8.5940°15.352° 1.1" 12.586°*12.586°*16.860° 1/2" 14.366°*12.397°*18.886° |
83.8g |
